23 Apr 2018
2 Comments

Setting Up the Intrepid’s Solar Ground Panels

The video below shows how the Intrepid carries its two 100-watt solar ground panels onboard, and how they are removed and deployed. The usual setup on Four Wheel campers is to carry one panel by using two aluminum rails attached underneath the bed area of the camper, but there isn’t enough of a vertical gap between the camper and the truck’s cab roof to stow two 100-watt panels in this way. Plus, the then-owner of Four Wheel personally interceded on the phone to dissuade me from using that method due to his fear that the combined weight of the panels and the inherent violence of off-roading might cause delamination of the board used in that area. I had wanted to use adhesive tape rather than drill for machine screws through the board from inside the camper, something I’m squeamish about when accuracy is vital. It’s a moot point, though. There isn’t enough physical space available.

So I designed, prepped and had a highly experienced welder assemble an aluminum carrier rack that is bolted to the forward jack mounts of the camper. It’s a twin-track affair which carries Read more…

Posted in Mod Squad, The Intrepid and tagged ,
23 Oct 2016
13 Comments

State of the Intrepid – Solar Power Mods

You want trauma? Try drilling and sinking sheet metal screws into a pristine, seamless 1-piece top.

You want trauma? Try drilling and sinking sheet metal screws into a pristine, seamless 1-piece top sheet, where every screw must intercept a supporting thinwall rib somewhere underneath. And it’s up to you to figure out exactly where those aluminum ribs might be.

The Grandby by default came with an electrical system intended to be powered off the Ford’s twin starting batteries. This is not a bad way to go if you travel a little each day, don’t use much power, and preferably swap in some Optima AGM deep cycle batteries under the hood to deal better with the dual-purpose stresses. Lots of overlanders do this, but it starts to make less sense once you begin to stay planted, use more power, and/or don’t care to lug along a generator and gas can. Stranding your own vehicle by depleting its starting battery is seldom advisable.

I recommend wiring an inexpensive digital DC voltmeter to your battery to get a rough idea of its state of charge. This one is simply perched on top of a Samlex 150-watt pure sine inverter, which allows even sensitive electronics to run safely. It uses less than 6 watts at idle by itself. Since Samlex recommended 10-gauge wire for my length of hookup wire, that's what I used. No unpleasant surprises.

I recommend wiring an inexpensive digital DC voltmeter to your battery to get a rough idea of its state of charge. This one is perched on top of a Samlex 150-watt pure sine inverter.

I was already sitting on five 3-year-old AGM batteries, as well as a suitable solar charge controller and four 200-watt solar panels. Whoops, overkill! Right? A distinct lack of storage space and roof acreage prompted me to keep just four of the batteries and the controller. Couldn’t I make do with fewer batteries? Yes, definitely. Just two 104Ah batteries would possibly Read more…

Posted in Mod Squad, The Intrepid and tagged , , ,
10 Feb 2016
8 Comments

Intrepid Solar, Part 1

Roof beams marked in pen, the first solar panel is taped to protect paint, and placed about where it is planned to go.

Roof beams marked in pen, the first solar panel is taped to protect paint, and placed about where it is planned to go.

Technically, the Intrepid’s solar system is fully up and rolling. I’m calling this post “Part 1″ because there’s still no place to stow the two Renogy 100-watt ground panels.

This is a long post. The executive summary is that three Aleko 100-watt solar panels and one 60W panel are now roof-mounted on the Four Wheel Grandby, using four pairs of 1.5″ x 1.5″ x 31″ aluminum L-angles that each span three structural roof beams. #8 x 1/2” self-tapping stainless steel screws were used as the fasteners. The roof panels feed a Morningstar TriStar MPPT 45A charge controller liberated from the Defiant, while the ground panels supply an Outback Smart Harvest MPPT 20A controller. A Battery Life Saver desulfator is wired in as well, controlled by an LED-lighted toggle switch. Four 104Ah Sun Extender AGM batteries have been stuffed into the Grandby’s bench seats. A rather complex wiring scheme has been used to minimize unequal draw and charging among the four batteries, with equally elaborate fusing to protect all positive and some negative cables running between the two benches. A 150-watt Samlex pure-sine inverter handles all AC power needs. There you go.

For those of you who are gluttons for punishment, here’s the nitty gritty. I was originally going to install one of Read more…

Posted in Mod Squad, The Intrepid and tagged , , , , ,
01 Jan 2016
25 Comments

Revenge of the Catch-22

IMGP1983

Per my last post on the topic of solar panels for the Mighty Intrepid/FWC Grandby, I had a decent planned setup with a 100W solar panel at each corner of the roof, each panel being held with a 20.5-inch long ABS adhesive mount fore and aft, for aero and dependability reasons. I figured that would be long enough to catch a couple of structural roof ribs under each one, and apply an abundance of adhesion to hold to the roof securely. The only real limitation was that I could come only so close to the roof edge because of tapering of the roof’s thickness.The panels would be held to the mounts with horizontal screws. The panels might be closer to the start of the taper than I liked, but it seemed promising.

As for using ground panels to add solar power, stowing a solar panel in slides mounted under the Grandby’s bed overhang has been done for awhile. After all, that platform is engineered to carry a heap of weight, being a 7″ or more vertical aluminum extrusion wrapped around the bed perimeter. Plywood forms the mattress platform, and a 20-pound panel hung under it should be no big deal, right? Given that the camper is now installed and that drilling holes from underneath is hit or miss because of its closeness to the truck cab’s roof, I thought about attaching a panel-carrying set of rails underneath, held by 3M VHB (Very High Bond) tape and supplemented toward each end with screws, since drilling there from underneath is not a problem. But what was the facing surface under this platform? There are a few different versions of VHB tape, each tailored for certain surfaces. I emailed Four Wheel Campers to ask.

This is what holds the bed platform, so there's no concern about hanging some weight under it - as long as it's done properly.

This is what holds the bed platform, so there’s no concern about hanging some weight under it – as long as it’s done properly.

What I promptly got back was a reply saying, “If you could please call us at ___-___-____, we can discuss a number of issues at the same time and wrap this up for you.” Say what? I’d expected Read more…

Posted in Mod Squad, The Intrepid and tagged , , , , ,
22 Oct 2015
23 Comments

Intrepid Solar Solutions

This 100W panel offered by Windy Nation appears to be identical, but comes with additional connectors.

This 100W panel offered by Windy Nation appears to be identical to Renogy’s, but comes with additional connectors. Its 20% efficiency is considered pretty good.

When it comes to angst in planning mods to the Four Wheel Granby, AKA Intrepid, fitting it out for solar comes right behind dealing with its lack of interior space. On the face of it, adding solar to the Granby is unusually easy: it comes prewired for solar whether you want it or not. There’s an SAE socket installed on the roof, and another on the back wall for plugging in ground-based solar panels. Order Four Wheel’s battery option, and you get your choice of one or two 80Ah (amp-hour) AGM batteries, as well as a battery separator to keep you from running down your truck’s starting battery. You can order their solar panels, whether roof-mounted, ground, or both, with a charge controller that comes along. It’s easy, it works well, and you’re rolling the instant you take delivery.

Four Wheel's 100W roof panel is one option that's light enough to cause no issues.

Four Wheel’s 100W roof panel is one option that’s light enough to cause no issues.

Heck, with 240 watts of panels available from the factory powering an optional 160-some Ah of batteries, it’s all anyone could want. I mean, it’s enough to run the compressor fridge and a laptop, as long as weather conditions are decent and you don’t overdo it. And, it’s a “top-heavy” system: there’s enough Read more…

Posted in Mod Squad, The Intrepid and tagged , , ,
07 Jan 2015
13 Comments

Solar Demystified

These are 195-watt solar panels, and where you put them is up to you or your rig's limitations.

These are 195-watt solar panels, and where you put them is up to you or your rig’s limitations.

I’m no expert on solar systems, but that of course doesn’t stop me from having opinions and expressing my ignorance. Since I’m currently having to engineer a simple solar system for another camper, I thought it timely to write this epistle on what to consider before it’s time to cough up your hard-earned dough.

I know that I’m supposed to break this up into smaller, frequent posts, but I find the loss in continuity disruptive, and kind of a gimmick to boost readership numbers. I have no sponsors, so there’s no point in artificially pumping up visits to impress commercial interests enough to give me money. Yeah, I’d like to have something for you every day just for its own sake, but that ain’t gonna happen. I almost have a life. This blog is based on providing complete and useful information or references, as well as inane trivia, in single packages that don’t force you to wait for the next installment. But at some 7,800 words, it does require tolerance on your part for unending tomes of ignorance. Enjoy.

For the purposes of this article, I’m sticking with simple, almost-affordable systems that you can easily design and build yourself. More costly and sophisticated systems, no. I’m electronically-challenged, and bottom feeder systems are my realm. They are relatively easy to design, install, and wire up.

Where to begin

It’s tempting to assume that the first order of the day is to wonder how many solar panels you’ll need, because that’s what Read more…

Posted in Mod Squad and tagged , , ,
22 Aug 2014
2 Comments

Damage Control! Report!

Solar panel #4 safely on the ground after being found hanging on one hook.

Solar panel #4 safely on the ground after being found hanging on one hook.

RVs are heavy – ask anyone at a fuel stop. But they also have a very large sail area, a trait which rarely works in their favor. They are highly subject to bad weather and, out west, there’s plenty of that to go around in the late summer.

A couple of nights ago, a very high wind came up in camp, one that wasn’t in any forecast. The forecasts said current wind was and would remain at 6 MPH. Night winds haven’t been unusual here in Wendover, blowing in well after sunset and rotating around in all directions for an hour or so. Often, it’s like throwing a switch on a fan.

Well, this one was a doozy. The good news was that it decided to blow in pretty much straight from the nose of the trailer, which poses the least threat to the Kleenex box aerodynamics of the Defiant. Wheel locks between each pair of trailer tires work quite well to resist any movement.

The wind had started in as usual, but didn’t let up this time, and I stayed up just short of midnight just to Read more…

Posted in Campsites, Daily Life, Mod Squad and tagged , , , ,
23 Dec 2013
2 Comments

What’s Your Angle, Bud?

With support poles at a slight tilt, this has been my only concession to following the sun's lower winter arc.

With support poles at a slight tilt, this has been my only concession to following the sun’s lower winter arc.

Well, I was out admiring the Enterprise again and noticed that the sun at noon was not even remotely perpendicular to the solar panels, which were too close to horizontal to be very efficient. A panel that’s markedly out of position in relation to the sun presents a smaller surface area to it, and captures less light. The limited daylight of the winter sun is bad enough, and so is the inability to physically follow it across the sky. Why waste it further by having the basic panel tilt way off?

I looked up the seasonal data for my latitude, which is just shy of 33 degrees above the equator. Turns out the recommended panel winter angle for my location is Read more…

Posted in Mod Squad, The Enterprise and tagged , ,
28 Oct 2013
4 Comments

Batten the Hatches Again!

A gorgeous day...with high winds.

A gorgeous day…with high winds.

Not a fascinating post, but it’s all part of daily life in this rig. The heat wave of 90+ degrees in Quartzsite is over, and it’s expected to be a long spate of low-80’s for quite a while, which is the top of my Ultimate Comfort Zone. The new temperature front moving in is expected to produce southwest wind gusts in the  45 MPH range though. That means take all precautions, so I staked down the telescoping poles supporting the solar panels, and added the tie-down ropes, two to a panel. None of it should be needed in a wind hitting the trailer at the southwest corner (the trailer, as always, is aimed straight west) because it tends to merely drive the panels downward instead of lifting them. Since I don’t plan to move a thing for many months though, I figured now is better than later. The highest winds should arrive in a couple of hours and continue through until suppertime. That isn’t preventing the Enterprise from rocking a bit right now, however.

A larger concern has been the relatively ineffective rubber wheel chocks. They seemingly were designed for smaller-diameter tires, because they don’t allow these tires any chance to Read more…

Posted in Daily Life, Mod Squad and tagged , ,
05 Oct 2013

Out For a Walk

A canal feeding brine back toward the Bonneville Salt Flats.

A canal feeding brine back toward the Bonneville Salt Flats.

Nothing spectacular today, which is nice for a change. The daytime temperature edged back into the 70’s today, and since I was already out to pump the camper’s waste tanks into the Tankmin in the Furd, I went for a 2-mile walk down the road heading for the Salt Flats. There are two 12-inch pipes coming out of the ground, each a hundred yards from the roadway. There must be a heckofa pump or two somewhere, because the flow rate out each of those pipes is impressive, and they flow 24/7. It seems that a potash plant on the other side of I-80 is returning leftover brine back to the salt flats.

That’s good, because the Bonneville Salt Flats used to be 90,000 acres in 1963, and today covers only 30,000 acres because of that plant. For speed freaks, that has reduced the former 10-mile track surface to just 7 miles. 18 inches of salt have been removed, and this voluntary return is hoped to slow further shrinkage, not hold or reverse it. Potash is a key ingredient in fertilizer, and this result makes sustainable methods of farming look like an admirable thing to me.

The last few days have been inordinately cold and windy, with highs at about 50. Officially, wind gusts registered Read more…

Posted in Daily Life and tagged , , | Leave a comment
